Quick Genius GP2 2000 Windlass
TMS-FSGP22024D06
For yachts 8 - 13 metres in length (26 - 43 ft)
Automatic Free-Fall System
Epicyclical gearbox
Integrated sensor and magnet for chain counter
Rope/Chain combination gypsy
With or without Drum
More Information
Features
Downloads
Quick Genius GP2 2000 Windlass Facts and Features:
- Horizontal on-deck windlasses
- Anodized aluminium in hard oxide base
- Rope and chain on a single gypsy
- Integrated sensor and magnet for chain counter
- Available with manual Free-Fall system
- Supplied with pressure lever
- IP66 watertight motor
- Epicyclical gearbox
- Automatic Free-Fall System
Automatic Free-Fall System
The Free-Fall technology allows free running of chain through the gypsy when lowering the anchor.
Included in the box: Contactor (Control Box) and Nylon handle
Not included in the box: Circuit Breaker, Switches and Controls
- Motor power 800 W
- Motor supply voltage 12 V ~ 24 V
- Maximum pull 900 Kg / 1984 lb
- Maximum working load 350 Kg / 772 lb
- Working load 120 Kg / 265 lb
- Current absorption @ working load (1) 96 A ~ 50 A
- Maximum chain speed (2) 29,6 m/min / 97.1 ft/min
- Maximum chain speed @ working load (2) 20 m/min 65.6 ft/min ~ 20,1 m/min 65.9 ft/min
- Weight without drum 10,2 Kg / 22.4 lb
- Weight with drum 11,5 Kg / 25.3 lb
- Weight with FF 10,9 Kg / 24 lb
The measurements are taken from after an initial period of use with a gypsy for 8 mm chain.
| Model | Power | LOA Metres | LOA Feet |
|---|---|---|---|
| GP2 2000 | 800 W | 8 - 13 m | 26 - 43 ft |
| Gypsy | Chain | Rope |
|---|---|---|
| 6mm | 6mm DIN 766 | 12mm 3 Strand |
| 8mm | 8mm DIN 766 | 12mm 3 Strand |
